45 Degree Elbow Buttweld Fitting

What Are 15-5 PH Fasteners?

Global Steel is a well-known supplier, importer, stockist, exporter, and manufacturer of 45 Degree Elbow Buttweld Fittings with high-performance solutions for a variety of industries. 45-degree elbows play a significant role in pipe fitting, offering a smooth direction change with an unobstructed flow of chemicals, gases, and liquids and other materials. Precision-engineered, our 45-degree elbows have a high demand in petrochemicals, oil & gas, power plants, pharmaceuticals, and water treatment plants industries.

Table of Content

45 Degree Elbow Buttweld Fitting Specification Chart
Material of 45 Degree Elbow Buttweld Fitting
Dimensions of 45 Degree Elbow Buttweld Fitting
People Also Search
Application Of Industries

45 Degree Elbow Buttweld Fitting, 45 Degree Elbow Buttweld Fitting Manufacturers, 45 Degree Elbow Buttweld Fitting Suppliers, 45 Degree Elbow Buttweld Fitting Stockists, 45 Degree Elbow Buttweld Fitting Exporters

A 45 Degree Elbow Buttweld Fitting is specifically designed for directional flow at 45 degrees. Unlike a 90-degree one with its sharp bend, a 45-degree one creates a transition, keeping pressure loss and turbulence in the pipe at a minimum. That is why it is most ideal for use in scenarios when a smooth flow is paramount. As a supplier, manufacturer, and stockist in whom one can trust, at Global Steel, we make a point to produce all our fittings in compliance with national and international standards, offering dependability and durability to our clients.

One of the most important advantages of using buttweld fittings is that they can integrate perfectly with the pipe system. With a leak-tight union, pipeline integrity is augmented through welding. For high temperature and high pressure operations, these fittings are used for durability and high tolerance for harsh environments. All our buttweld 45-degree elbows at Global Steel undergo rigorous testing for materials, dimensions, and hydrostatic testing, offering flawless performance.

45 Degree Elbow Buttweld Fitting Manufacturers in India, 45 Degree Elbow Buttweld Fitting Suppliers in India, 45 Degree Elbow Buttweld Fitting Stockists in India, 45 Degree Elbow Buttweld Fitting Exporters in India

At Global Steel, we're happy to serve your one-stop-shop for any pipe needs. With years of expertise in manufacturing, supplying, stocking, exporting, and importing, we're determined to deliver high-quality 45 Degree Elbow Buttweld Fittings that guarantee dependability and efficiency. Get in contact with us today and explore our full range of buttweld fittings and indulge in unmatched quality and service.

45 Degree Elbow Buttweld Fitting Manufacturers in Mumbai, 45 Degree Elbow Buttweld Fitting Suppliers in Mumbai, 45 Degree Elbow Buttweld Fitting Stockists in Mumbai, 45 Degree Elbow Buttweld Fitting Exporters in Mumbai

45 Degree Elbow Buttweld Fitting Specifications

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	45 Degree Elbow
45 Degree Weld Elbow Pipe Fittings size	Seamless Butt Weld Fittings: 1/2" - 10" Welded Butt Weld Fittings: 1/2" - 48"
45 Degree Elbow Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
45 Degree Pipe Elbow Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
45 Degree Weld Elbow Types	Seamless / ERW / Welded / Fabricated Pipe Fittings
45 Degree Reducing Elbow Type	DN15-DN1200
Connection	Welding
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings
Size Range	½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
45 Degree Elbow Fittings	Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Manufacturing process	Push, Press, Forge, Cast, etc.
45 Degree Weld Elbow Fittings Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Key markets and industries for 45 Degree Elbow	Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids.
Application	Fittings To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc ASME B16.9 Schedule 10 45 Degree Elbow are an economical alternative for lower-pressure applications. ANSI B16.9 Schedule 40 45 Degree Elbow have a thicker wall for higher-pressure applications.

Material of 45 Degree Elbow

Carbon Steel 45 Degree Elbow	ASTM A234 WPB 45 Degree Elbow ASTM A420 WPL6 45 Degree Pipe Elbow WPHY 42 45 Degree Reducing Elbow WPHY 52 45 Degree Elbow WPHY 60 45 Degree Weld Elbow WPHY 65 45 Degree Weld Elbow WPHY 70 45 Degree Pipe Elbow
Stainless Steel 45 Degree Elbow	ASTM A403 WP304 45 Degree Pipe Elbow ASTM A403 WP304L 45 Degree Weld Elbow ASTM A403 WP316 45 Degree Elbow ASTM A403 WP316L 45 Degree Pipe Elbow ASTM A403 WP317 45 Degree Weld Elbow ASTM A403 WP317L 45 Degree Pipe Elbow ASTM A403 WP321 45 Degree Pipe Elbow ASTM A403 WP321H 45 Degree Weld Elbow ASTM A403 WP347 45 Degree Elbow ASTM A403 WP347H 45 Degree Reducing Elbow
Alloy Steel 45 Degree Pipe Elbow	ASTM A234 WP5 45 Degree Weld Elbow ASTM A234 WP9 45 Degree Elbow ASTM A234 WP11 45 Degree Elbow ASTM A234 WP22 45 Degree Weld Elbow ASTM A234 WP91 45 Degree Pipe Elbow
Inconel 45 Degree Weld Elbow	Inconel 600 45 Degree Elbow Inconel 601 45 Degree Pipe Elbow Inconel 625 45 Degree Reducing Elbow Inconel 718 45 Degree Pipe Elbow Inconel x750 45 Degree Elbow
Copper 45 Degree Elbow	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910,C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000,C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, etc
Copper Nickel 45 Degree Pipe Elbow	Copper Nickel 90/10 (C70600 ) 45 Degree Pipe Elbow, Cupro Nickel 70/30 (C71500) 45 Degree Elbow, UNS C71640 45 Degree Elbow
Brass 45 Degree Reducing Elbow	3602 / 2604 / H59 / H62 / etc.
Hastelloy 45 Degree Weld Elbow	Hastelloy C276 (UNS N10276) 45 Degree Elbow, C22 (UNS N06022) 45 Degree Pipe Elbow, C4 45 Degree Elbow, C2000 45 Degree Weld Elbow, B2 45 Degree Elbow, B3 45 Degree Elbow, X 45 Degree Reducing Elbow
Monel 45 Degree Weld Elbow	Monel 400 (UNS No. N04400) 45 Degree Elbow, Monel 500 (UNS No. N05500) 45 Degree Weld Elbow
Alloy 20 45 Degree Elbow	Carpenter® 20 Alloy 45 Degree Weld Elbow, Alloy 20Cb-3 45 Degree Pipe Elbow
Aluminium 45 Degree Weld Elbow	5052 /6061/ 6063 / 2017 / 7075 / etc.
Nickel 45 Degree Pipe Elbow	Nickel 200 45 Degree Elbow, Nickel 201 45 Degree Reducing Elbow
Duplex 45 Degree Weld Elbow	S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Super Duplex 45 Degree Elbow	S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Incoloy 45 Degree Elbow	Incoloy 800 45 Degree Reducing Elbow, Incoloy 800H 45 Degree Elbow, Incoloy 800HT (UNS N08800) 45 Degree Weld Elbow, Incoloy 825 (UNS N08825) 45 Degree Pipe Elbow
254 Smo 45 Degree Pipe Elbow	SMO 254/6Mo 45 Degree Elbow, UNS S31254 45 Degree Elbow, DIN 1.4547 45 Degree Weld Elbow
Nimonic 45 Degree Weld Elbow	Nimonic 75 45 Degree Elbow, Nimonic 80A 45 Degree Elbow, Nimonic 90 45 Degree Pipe Elbow
Other 45 Degree Reducing Elbow material	Tin bronze 45 Degree Weld Elbow, Alumunum bronze 45 Degree Weld Elbow, Lead bronze 45 Degree Weld Elbow
Titanium 45 Degree Pipe Elbow	ASTM B381 Titanium Gr. 1 45 Degree Pipe Elbow ASTM B381 Titanium Gr. 2 45 Degree Weld Elbow ASTM B381 Titanium Gr. 4 45 Degree Weld Elbow ASTM B381 Titanium Gr. 5 45 Degree Elbow ASTM B381 Titanium Gr. 7 45 Degree Pipe Elbow

Dimensions of 45 Degree Elbow

Nom. Pipe Size	Pipe Sched. or No.	Center- to-end Dimen.	Outside Dia.	Inside Dia.	Wall Thick.	Approx. Weight (lb.)
		F	OD	ID	T
STANDARD WEIGHT
1/2	40	5/8	0.840	0.622	0.109	0.1
3/4	40	7/16	1.050	0.824	0.113	0.1
1	40	7/8	1.315	1.049	0.133	0.2
1 1/4	40	1	1.660	1.380	0.140	0.4
1 1/2	40	1 1/8	1.900	1.610	0.145	0.5
2	40	1 3/8	2.375	2.067	0.154	0.9
2 1/2	40	1 3/4	2.875	2.469	0.203	1.5
3	40	2	3.500	3.068	0.216	2.5
3 1/2	40	2 1/4	4.000	3.548	0.226	3.5
4	40	2 1/2	4.500	4.026	0.237	4.8
5	40	3 1/8	5.563	5.047	0.258	7.8
6	40	3 3/4	6.625	6.065	0.280	12
8	40	5	8.625	7.981	0.322	23
10	40	6 1/4	10.750	10.020	0.365	42
12	–	7 1/2	12.750	12.000	0.375	61
14	30	8 3/4	14.000	13.250	0.375	79
16	30	10	16.000	15.250	0.375	103
18	–	11 1/4	18.000	17.250	0.375	132
20	20	12 1/2	20.000	19.250	0.375	160
22	20	13 1/2	22.000	21.250	0.375	195
24	20	15	24.000	23.250	0.375	238
EXTRA STRONG
Nom. Pipe Size	Pipe Sched. or No.	Center- to-end Dimen.	Outside Dia.	Inside Dia.	Wall Thick.	Approx. Weight (lb.)
		F	OD	ID	T
1/2	80	5/8	0.840	0.546	0.147	0.2
3/4	80	7/16	1.050	0.742	0.154	0.3
1	80	7/8	1.315	0.957	0.179	0.4
1 1/4	80	1	1.660	1.278	0.191	0.5
1 1/2	80	1 1/8	1.900	1.500	0.200	0.6
2	80	1 3/8	2.375	1.939	0.218	1.1
2 1/2	80	1 3/4	2.875	2.323	0.276	2.1
3	80	2	3.500	2.900	0.300	3.5
3 1/2	80	2 1/4	4.000	3.364	0.318	4.8
4	80	2 1/2	4.500	3.826	0.337	6.5
5	80	3 1/8	5.563	4.813	0.375	11
6	80	3 3/4	6.625	5.761	0.432	18
8	80	5	8.625	7.625	0.500	35
10	60	6 1/4	10.750	9.750	0.500	56
12	–	7 1/2	12.750	11.750	0.500	80
14	–	8 3/4	14.000	13.000	0.500	100
16	40	10	16.000	15.000	0.500	131
18	–	11 1/4	18.000	17.000	0.500	172
20	30	12 1/2	20.000	19.000	0.500	210
22	30	13 1/2	22.000	21.000	0.500	259
24	–	15	24.000	23.000	0.500	302
